L&T 3Ph Gen Meter

📘 L&T 3-Phase Generation Meter – Description

The L&T 3-Phase Generation Meter is a high-precision, durable, and DISCOM-approved metering solution designed for commercial and industrial solar power plants.
It accurately measures the total solar energy generated, ensuring transparency for net-metering, gross-metering, and open-access applications.

✨ Key Features

• Class 0.5s / Class 1 accuracy for highly reliable generation tracking

• Tamper-resistant construction with multiple detection features

• Large backlit LCD for real-time monitoring (kWh, voltage, current, PF, frequency)

• Supports bidirectional metering if required by distribution companies

• Designed for continuous operation in harsh Indian environments

• Wide dynamic range enabling accurate measurement even at low loads

• DLMS/RS-232/Optical Port communication options (model-dependent)

• Fully compliant with IS 15959, IS 14697 and other regulatory norms

📦 Suitable Applications

• Commercial & Industrial solar rooftop systems

• MW-scale ground-mounted solar plants

• Net-metering / Gross-metering projects

• Utility-approved solar installations

• Energy auditing and load study applications

🛠 Key Technical Highlights

• Phase: 3-Phase, 4-Wire

• Voltage Range: 3 × 240/415V AC

• Frequency: 50 Hz

• Accuracy Class: Class 0.5s / 1.0

• Display: Multi-line LCD

• Communication: Optical port / RS-232 / DLMS

• Standards: IS 14697, IS 15959 compliant
