- Wider MPPT Range
- Anti-Islanding protection
- Low start-up voltage
- IP65 protection
- 96.43% efficiency
- Natural cooling convection
- In-built Zero Export Device
- Remote monitoring and intelligent maintenance
- In-house remote monitoring application 'Selec Solar'
Brief Specifications
| Phase, Rating |
1 phase,1.5 kW |
| Max. allowable power |
2.25 kW |
| Start-up Voltage |
50 V DC |
| MPPT Range |
50-550 V DC |
| Max input current per MPPT |
17 A |
| Number of MPPT |
1 |
| Max o/p current |
7.14 A |
| Max s/c current per MPPT |
20 A |
| Grid Voltage Range |
90-290 V |
| THD % |
<3% at rated load |
| Max. Efficiency |
96.43% |
| Max. Altitude |
4000m |
| Monitoring |
RS485 (Default)/ Wi-Fi /GSM (To be ordered along with inverter separately) |
| Protections |
IP65, DC reverse polarity, Short Circuit, Over Current, Over voltage/Under Voltage, Over frequency/Under Frequency, Insulation resistance monitoring, Residual current detection, Surge, Islanding, Temperature, Integrated DC Switch (Optional), Integrated AFCI (Optional) |
| Certifications |
BIS, IEC |
This meter comes with a 10-year replacement warranty, ensuring long-term reliability and complete peace of mind for the user.
